ProX XTH-MLT3US10FT | 10ft Open-Bottom Pre-Rig Truss | Rotatable Steel Fork Connectors

ProX XTH-MLT3US10FT  (ProX XTHMLT3US10FT)

Pre-Rig Truss

The ProX XTH-MLT3US10FT MLT THREE is a 10-foot open-bottom pre-rig truss designed for touring productions, LED video systems, rental companies, concert stages, and professional event installations. Its open construction provides direct access for mounting moving lights, LED fixtures, and video modules inside the truss, helping crews prepare equipment in advance and reduce repetitive rigging during load-in and load-out.

ProX XTH-MLT3US10FT Competitive Differences

• Open-bottom design eliminates a closed lower head frame, providing unobstructed access for moving lights, LED fixtures, video modules, and hanging frames.
• Rotatable hardened-steel male and female fork connectors extend up to 60 mm for straight, curved, angled, and circular truss configurations.
• Unique Fork-Locking System™ allows connector angles to be set and secured for specialized layouts and pre-tension or camber configurations.
• Individual fork connectors are field replaceable, allowing damaged connector hardware to be serviced without replacing the complete truss section.

ProX XTH-MLT3US10FT Description

The ProX XTH-MLT3US10FT is part of the HOF MLT THREE pre-rig truss system and is built for production environments where lighting and video equipment must be installed, transported, and redeployed efficiently. At 10 feet long, the section can cover wider spans with fewer connection points than shorter truss sections, making it well suited for large stages, touring systems, and long LED video wall runs.

The truss is manufactured from EN AW 6082 T6 aluminum with 48.3 x 4.5 mm main tubes and 30 x 3 mm bracing. HOF Heavy Duty coating in RAL 9005 gloss black provides a durable exterior finish intended for repeated handling in touring and rental environments.

Included hardened-steel male and female fork connectors rotate to support straight runs as well as horizontal and vertical curved configurations. The forks extend up to 60 mm and can be individually replaced when necessary. The fork-locking design also allows crews to establish specific angles and pre-tension or camber settings before deployment to help manage deflection in loaded configurations.

The open-bottom structure is especially useful for pre-rigged lighting and LED video applications because fixtures and complete video modules can be positioned inside the truss without a closed lower frame obstructing access. A compatible folding dolly with telescopic legs is available separately for transporting pre-rigged assemblies, and an optional double-rail system allows fixtures to be suspended at two different levels inside the truss. This listing includes the 10-foot truss section and male and female steel fork connectors only.

XTH-MLT3US10FT Features

• 10-foot HOF MLT THREE professional pre-rig truss
• Open-bottom design with no closed lower head frame
• Direct access for moving lights, LED fixtures, video modules, and hanging frames
• Designed for touring, rental, staging, concert, and LED video applications
• Hardened-steel male and female rotatable fork connectors included
• Fork connectors extend up to 60 mm
• Supports straight, horizontal-curve, vertical-curve, angled, and circular configurations
• Unique Fork-Locking System™ for securing selected connector angles
• Supports pre-tension or camber configurations to help compensate for loaded deflection
• Individually field-replaceable fork connectors
• EN AW 6082 T6 aluminum construction
• 48.3 x 4.5 mm main tubes
• 30 x 3 mm bracing
• HOF Heavy Duty coating in RAL 9005 gloss black
• Compatible with appropriate professional 48.3 mm fork-style truss systems
• Optional double-rail system available separately for dual-level fixture suspension
• Compatible folding transport dolly with telescopic legs available separately
• Structural analysis documentation available for line-load, vertical, upside-down, curved, and cantilever configurations
• Folding dolly and telescopic dolly legs not included

XTH-MLT3US10FT Specifications

• Truss Length: 10 ft (3048 mm)
• Exterior Dimensions: 120 x 22 x 12 in (3048 x 559 x 305 mm)
• Material: EN AW 6082 T6 aluminum
• Main Tube: 48.3 x 4.5 mm (1.90 x 0.18 in)
• Bracing: 30 x 3 mm (1.18 x 0.12 in)
• Connector Type: Rotatable hardened-steel male and female fork connectors
• Fork Extension: Up to 60 mm (2.36 in)
• Finish: HOF Heavy Duty coating
• Color: RAL 9005 gloss black
• Weight: Approximately 135 lb (61.2 kg)
• Country of Manufacture: PRC
• Suggested Shipping Method: LTL

What's In The Box

• (1) HOF MLT THREE 10-Foot Pre-Rig Truss Section
• Male and Female Rotatable Steel Fork Connectors
